YASKAWA SIGMA-7 Series User Manual

viii

Σ-7-Series
Σ-7S/Σ-7W
SERVOPACK
Product Manuals
Σ-7-Series AC Servo Drive
Σ-7S SERVOPACK with
MECHATROLINK-III
Communications References
Product Manual
SIEP S800001 28
Provide detailed information on
selecting Σ-7-Series Σ-7S and
Σ-7W SERVOPACKs; installing,
connecting, setting, testing in trial
operation, tuning, monitoring, and
maintaining Server Drives; and
other information.
Σ-7-Series AC Servo Drive
Σ-7S SERVOPACK with
MECHATROLINK-II
Communications References
Product Manual
SIEP S800001 27
Σ-7-Series AC Servo Drive
Σ-7S SERVOPACK with
Analog Voltage/Pulse Train
References
Product Manual
SIEP S800001 26
Σ-7-Series AC Servo Drive
Σ-7S SERVOPACK
Command Option Attachable
Type with INDEXER Module
Product Manual
SIEP S800001 64
Σ-7-Series AC Servo Drive
Σ-7S SERVOPACK
Command Option Attachable
Type with DeviceNet Module
Product Manual
SIEP S800001 70
Σ-7-Series AC Servo Drive
Σ-7W SERVOPACK with
MECHATROLINK-III
Communications References
Product Manual
SIEP S800001 29

Σ-7-Series
Σ-7S/Σ-7W
SERVOPACK with
Hardware Option
Specifications
Product Manuals
Σ-7-Series AC Servo Drive
Σ-7S/Σ-7W SERVOPACK with
Hardware Option
Specifications
Dynamic Brake
Product Manual
SIEP S800001 73
Provide detailed information on
Hardware Options for Σ-7-Series
SERVOPACKs.
Σ-7-Series AC Servo Drive
Σ-7W/Σ-7C SERVOPACK with
Hardware Option
Specifications
HWBB Function
Product Manual
SIEP S800001 72
Continued on next page.
Continued from previous page.
Classification Document Name Document No. Description

YASKAWA SIGMA-7 Series Specifications

General

Encoder Resolution	24-bit absolute encoder
Pollution Degree	2
Cooling Method	Natural cooling or forced air cooling
Control Method	Vector control
Communication Protocols	EtherCAT, MECHATROLINK-III
Input Voltage	AC 200 V, AC 400 V
Rated Output	Varies by model
Safety Function	STO (Safe Torque Off), SS1 (Safe Stop 1), SS2 (Safe Stop 2), SLS (Safely Limited Speed), SBC (Safe Brake Control)
Power Supply Voltage	AC 200 V, AC 400 V
Rated Output Current	Varies by model
Protection Functions	Overload, overvoltage, undervoltage, overheat, short circuit
Operating Temperature	0°C to 55°C
Storage Temperature	-20°C to 65°C
Vibration Resistance	5.9 m/s² at 10 Hz to 55 Hz
Ambient Humidity	5% to 95% RH (non-condensing)
Altitude	Up to 1000 m
Installation	Panel mounted
