YASKAWA SIGMA-7 Series User Manual

ix
Σ-7-Series
Σ-7S/Σ-7W SERVOPACK
FT/EX
Product Manuals
Σ-7-Series AC Servo Drive
Σ-7S SERVOPACK with
FT/EX Specification for
Indexing Application
Product Manual
SIEP S800001 84
Provide detailed information on the
FT/EX Option for Σ-7-Series
SERVOPACKs.
Σ-7-Series AC Servo Drive
Σ-7S SERVOPACK with
FT/EX Specification for
Tracking Application
Product Manual
SIEP S800001 89
Σ-7-Series AC Servo Drive
Σ-7S SERVOPACK with
FT/EX Specification
for Application with
Special Motor,
SGM7D Motor
Product Manual
SIEP S800001 91
Σ-7-Series AC Servo Drive
Σ-7S SERVOPACK with
FT/EX Specification
for Press and Injection
Molding Application
Product Manual
SIEP S800001 94
Σ-7-Series AC Servo Drive
Σ-7S SERVOPACK with
FT/EX Specification
for Transfer and Alignment
Application
Product Manual
SIEP S800001 95
Σ-7-Series AC Servo Drive
Σ-7S SERVOPACK with
FT/EX Specification
for Torque/Force Assistance
for Conveyance Application
Product Manual
SIEP S800002 09
Σ-7-Series AC Servo Drive
Σ-7S SERVOPACK with
FT/EX Specification
for Cutting Application
Feed Shaft Motor
Product Manual
SIEP S800002 10
Σ-7-Series AC Servo Drive
Σ-7S SERVOPACK with
FT/EX Specification
for Three-Point Latching
for Conveyance Application
Product Manual
SIEP S800002 17
Σ-7-Series AC Servo Drive
Σ-7S SERVOPACK with
FT/EX Specification
for Semi-/Fully-Closed Loop
Control Online Switching
for Conveyance Application
Product Manual
SIEP S800002 27
Σ-7-Series AC Servo Drive
Σ-7W SERVOPACK with
FT/EX Specification
for Gantry Applications
Product Manual
This manual
(SIEP S800002 29)
Continued on next page.
Continued from previous page.
Classification Document Name Document No. Description

YASKAWA SIGMA-7 Series Specifications

General

Encoder Resolution	24-bit absolute encoder
Pollution Degree	2
Cooling Method	Natural cooling or forced air cooling
Control Method	Vector control
Communication Protocols	EtherCAT, MECHATROLINK-III
Input Voltage	AC 200 V, AC 400 V
Rated Output	Varies by model
Safety Function	STO (Safe Torque Off), SS1 (Safe Stop 1), SS2 (Safe Stop 2), SLS (Safely Limited Speed), SBC (Safe Brake Control)
Power Supply Voltage	AC 200 V, AC 400 V
Rated Output Current	Varies by model
Protection Functions	Overload, overvoltage, undervoltage, overheat, short circuit
Operating Temperature	0°C to 55°C
Storage Temperature	-20°C to 65°C
Vibration Resistance	5.9 m/s² at 10 Hz to 55 Hz
Ambient Humidity	5% to 95% RH (non-condensing)
Altitude	Up to 1000 m
Installation	Panel mounted
