Administrator’s Guide for SIP-T2 Series/T19(P) E2/T4 Series/CP860 IP Phones
842
The call cannot be set up successfully.
User A Proxy Server User B
F1. INVITE B
F2. INVITE B
F3. 100 Trying
F4. 100 Trying
F5. 486 Busy Here
F6. 486 Busy Here
F7. ACK
F8. ACK
Step
Action
Description
F1
INVITE—User A to Proxy
Server
User A sends the INVITE message to a
proxy server. The INVITE request is an
invitation to User B to participate in a
call session.
In the INVITE request:
 The IP address of User B is inserted
in the Request-URI field.
 User A is identified as the call
session initiator in the From field.
 A unique numeric identifier is
assigned to the call and is inserted
in the Call-ID field.
 The transaction number within a
single call leg is identified in the
CSeq field.
 The media capability User A is
ready to receive is specified.
 The port on which User B is
prepared to receive the RTP data is
specified.
F2
INVITE—Proxy Server to User
B
The proxy server maps the SIP URI in the
To field to User B. Proxy server forwards
the INVITE message to User B.
F3
100 Trying—User B to Proxy
User B sends a SIP 100 Trying response

Yealink SIP-T48G Specifications

General

Expansion module support	Yes
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Volume control	-
Display diagonal	7 \
Display resolution	800 x 480 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
AC adapter input voltage	100 - 240 V
Number of handles included	1 pc(s)

Weight and Dimensions

Width	266 mm
Height	185 mm
