Yealink SIP-T48G Administrator's Guide

Administrator’s Guide for SIP-T2 Series/T19(P) E2/T4 Series/CP860 IP Phones
510
To configure a paging list key via web user interface:
1. Click on DSSKey->Line Key (or Programable Key).
2. In the desired DSS key field, select Paging List from the pull-down list of Type.
3. (Optional.) Enter the string that will appear on the LCD screen in the Label field.
4. Click Confirm to accept the change.
To configure a multicast paging key via phone user interface:
1. Press Menu->Features->DSS Keys.
2. Select the desired DSS key.
3. Press or , or the Switch soft key to select Key Event from the Type field.
4. Press or , or the Switch soft key to select Multicast Paging from the Key
Type field.
5. (Optional.) Enter the string that will appear on the LCD screen in the Label field.
6. Enter the multicast IP address and port number in the Value field.
7. Press the Save soft key to accept the change.
To configure a paging list key via phone user interface:
1. Press Menu->Features->DSS Keys.
2. Select the desired DSS key.
3. Press or , or the Switch soft key to select Key Event from the Type field.
4. Press or , or the Switch soft key to select Paging List from the Key Type
field.
5. (Optional.) Enter the string that will appear on the LCD screen in the Label field.
6. Press the Save soft key to accept the change.
IP phones can receive an RTP stream from the pre-configured multicast address(es)
without involving SIP signaling, and can handle the incoming multicast paging calls
differently depending on the configurations of Paging Barge and Paging Priority Active.

Yealink SIP-T48G Specifications

General

Expansion module support	Yes
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Volume control	-
Display diagonal	7 \
Display resolution	800 x 480 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
AC adapter input voltage	100 - 240 V
Number of handles included	1 pc(s)

Weight and Dimensions

Width	266 mm
Height	185 mm
