5-51
IM AQ6370D-01EN
Measurement
5
5.19 Analog Out
Explanation
The saturation level and noise level varies depending on the REF level.
The table below shows the relationship between the REF level and the saturation level.
REF LEVEL(dBm or dBm/nm) Saturation Level * (dBm)
REF > 0 23 dBm or more
0 < = REF > -10 13 dBm or more
-10 < = REF > -20 3 dBm or more
-20 < = REF > -30 -7 dBm or more
-30 < = REF -17 dBm or more
* At wavelength 1450 to 1620 nm
ANALOG OUT Output Specifications
Output saturation voltage +6 V or more, +8 V or less
Bandwidth 10 kHz or more
Load 1 kΩ or more
