6-50
IM AQ6370D-01EN
Finding the Level Peak/Bottom to the Left of the Marker
6.
With the moving marker displayed at a waveform peak or bottom, press the NEXT
SEARCH LEFT soft key. The moving marker is placed on the peak (maximum
level value) or bottom (minimum level value) to the left of its current position.
Setting the Minimum Peak/Bottom Difference of the Mode Judgment
Reference
1.
Press PEAK SEARCH. The menu for detecting the peak value is displayed.
2.
Press the MORE 1/2 soft key.
3.
Press the MODE DIFF soft key. The screen for setting the minimum peak/bottom
difference of the mode judgment reference is displayed.
4.
Enter a peak/bottom difference using the rotary knob, arrow keys, or numeric key
pad.
5.
Press nm/ENTER.
Auto Search
1.
Press PEAK SEARCH. The menu for searching for the peak value is displayed.
2.
Press the MORE 1/2 soft key.
3.
Press the AUTO SEARCH soft key.
6.13 Single Search
To Next Page
