SORT BY
The detected marker values are displayed as a list in the data area. This setting sets the
sort order of the detection list.
WL: Wavelengths are displayed in order starting from the shortest wavelength.
LVL: For the peak search, levels are displayed in order starting from the highest level.
For the bottom search, levels are displayed in order starting from the lowest level.
PEAK SEARCH
A peak search (a search for the maximum level values) is performed on the active
trace waveform. Fixed markers are displayed on the peak points. The moving marker
is displayed on the maximum peak (the maximum level value). The marker values are
displayed in the data area. If the peaks are off the screen, their markers are displayed at
the top or bottom edge of the screen. Even in this situation, the correct marker values are
displayed.
After the measurement has completed, you can use the rotary knob to move the moving
marker. You can use the arrow keys to scroll through the data area.
BOTTOM SEARCH
A bottom search (a search for the minimum level values) is performed on the active
trace waveform. Fixed markers are displayed on the bottom points. The moving marker
is displayed on the minimum bottom (the minimum level value). The marker values are
displayed in the data area. If the bottoms are off the screen, their markers are displayed
at the top or bottom edge of the screen. Even in this situation, the correct marker values
are displayed.
After the measurement has completed, you can use the rotary knob to move the moving
marker. You can use the arrow keys to scroll through the data area.
Other Soft Keys
The functions of the following soft keys displayed on the PEAK SEARCH menu are the
same as the functions explained in the previous section on the single search. For details,
see the explanation in the previous section.
NEXT LEVEL SEARCH
NEXT SEARCH RIGHT
NEXT SEARCH LEFT
SET MARKER
SET
CLEAR MARKER
CLEAR
ALL MARKER CLEAR
MODE DIFF
SEARCH/ANA L1-L2
SEARCH/ANA ZOOM AREA
AUTO SEARCH
Note
The MODE DIFF (mode judgment reference)—the peak/bottom difference—setting is shared
between the multi search and single search.
6.14 Multi Search
