7-2
IM AQ6370D-01EN
7.1 Spectrum Width Measurement
If you only want to change the THRESH LEVEL, you can also do so with the SPEC
WIDTH THRESH soft key.
Changing the Threshold Value for Each Algorithm
4.
Continuing on from step 3, press the SPEC WIDTH THRESH soft key. The
threshold setting screen is displayed.
5.
Enter a value using the rotary knob, arrow keys, or numeric key pad.
6.
Press ENTER.
Automatic Analysis on Each Sweep
4.
Continuing on from step 3, press the AUTO ANALYSIS OFF ON soft key to select
ON. At the end of each sweep, the SPEC WIDTH, ANALYSIS 1, or ANALYSIS 2
function that was selected is executed automatically.
Note
• If the AUTO SEARCH soft key is ON when the AUTO ANALYSIS soft key is turned ON,
AUTO SEARCH is automatically turned OFF.
• When the AUTO ANALYSIS soft key is set to ON, is displayed at the bottom of the
screen in inverse video.
Saving Analysis Results
2.
Continuing on from step 1, press the MORE 1/2 soft key.
3.
Press the RESULT SAVE soft key. The file list is displayed.
4.
For the subsequent steps, see section 8.5, “Saving/Loading Analysis Results
Data.”
