8-26
IM AQ6370D-01EN
Explanation
You can save measured waveform data as a single file in internal memory or USB
storage media, or load previously saved data into traces A through G for display.
Extension
Files are saved under the extension CSV.
File Name
You can save files by assigning their names automatically or with specific names.
If you do not specify a file name, the following file name will be assigned automatically
according to the AUTO FILE NAME setting.
When AUTO FILE NAME is set to NUM
File name: WXXXX.CSV
XXXX is a serial number from 0000 to 9999
When AUTO FILE NAME is set to DATE
File name: Wyyyymmdd_hhmmss.CSV
yyyymmdd: Year (Gregorian) month day
hhmmss: Hour (24 hours) minute second
(Date/time when the file list was updated)
Note
• The date/time used when file names are assigned based on the date through remote
commands or program commands is the date/time when the file is created.
• Only use the characters allowed in file names by MS-DOS when changing a file name.
The maximum file name length is 56 characters (including the extension). The following
characters can be used in file names.
!#$%&’()-
0123456789@
ABCDEFGHIJKLMNOPQRSTUVWXYZ^
abcdefghijklmnopqrstuvwxyz{}¯
File Size
The maximum file size differs depending on the data being saved. Make sure the save
destination has sufficient space before saving.
Sorting files
The file list can be sorted in ascending order by FILE NAME, FILE DAT, or FILE LABEL.
8.4 Saving/Loading Displayed Data(All Trace)
