8-44
IM AQ6370D-01EN
Selecting a Program Number to Save
8.
Press the CURSOR soft key, then set the cursor selection to DOWN (on the
program list side).
9.
Select the program number of the load destination using the rotary knob, arrow
keys, or numeric key pad.
Executing the Load
10.
Press the EXECUTE soft key. The file is loaded and registered to the specified
program number.
When the RETURN soft key is pressed, the file is not loaded. The screen returns
to the previous stage.
Note
After loading program files (*.PG6) that were saved by the AQ6370 when the parameter of the
CHOPPER command was “CHOP,” the parameter becomes “SWITCH.”
8.7 Saving/Loading Program Data
