YOKOGAWA AQ6370D User Manual

8-49
IM AQ6370D-01EN
Saving/Loading Data
1
2
3
4
5
6
7
8
9
10
11
App
Index
Explanation
Extensions
The extensions used when saving are as follows.
BMP (bit-mapped format): .BMP
TIFF: .TIF
File Name
You can save files by assigning their names automatically or with specific names.
If you do not specify a file name, the following file name will be assigned automatically
according to the AUTO FILE NAME setting.
When AUTO FILE NAME is set to NUM
File name: WXXXX.BMP (or .TIF)
XXXX is a serial number from 0000 to 9999
When AUTO FILE NAME is set to DATE
File name: Wyyyymmdd_hhmmss.BMP (or .TIF)
yyyymmdd: Year (Gregorian) month day
hhmmss: Hour (24 hours) minute second
(Date/time when the file list was updated)
Note
• The date/time used when file names are assigned based on the date through remote
commands or program commands is the date/time when the file is created.
• Only use the characters allowed in file names by MS-DOS when changing a file name.
The maximum file name length is 56 characters (including the extension). The following
characters can be used in file names.
!#$%&’()-
0123456789@
ABCDEFGHIJKLMNOPQRSTUVWXYZ^
abcdefghijklmnopqrstuvwxyz{}¯
Color
B&W: You can save the file in black.
COLOR: You can save the file in color.
PRESET COL: You can save the file, only waveforms and markers in color, all other
items in black & white.
Data Format
You can save the file as a bit-mapped (BMP) or TIFF file.
File Size
The file size differs depending on the data format and color specified.
BMP (color): Differs depending on the display color.
BMP (B&W): Approximately 52 KB
TIFF (color): Approximately 412 KB
TIFF (black & white): Approximately 52 KB
8.8 Saving/Loading Image Data
