YOKOGAWA AQ6370D User Manual

9-3
IM AQ6370D-01EN
Other Operations
1
2
3
4
5
6
7
8
9
10
11
App
Index
The initial values for each setting are shown below.
SWEEP
Function Initial Value Maximum Value Minimum Value
SEGMENT POINT***** 1 50001 1
SWEEP MKR L1-L2 OFF/ON OFF - -
SWEEP INTERVAL *****s MINIMUM=0 99999 MINIMUM=0
CENTER
Function Initial Value Maximum Value Minimum Value
CENTER WL ****.***nm 1150.000 1700.000 600.000
CENTER FREQ ***.****THz 338.0013 500.0000 176.5000
START WL ****.***nm 600.000 1700.000 50.000
START FREQ ***.****THz 176.3485 500.0000 11.5000
STOP WL ****.***nm 1700.000 2250.000 600.000
STOP FREQ ***.****THz 499.6541 665.0000 176.5000
AUTO CENTER OFF/ON OFF - -
SPAN
Function Initial Value Maximum Value Minimum Value
SPAN****.*nm 1100.0 1100.0 0 / 0.1
SPAN FREQ***.**THz 323.31 330.00 0.00
START WL****.***nm 600.000 1700.000 50.000
START FREQ***.****THz 176.3485 500.0000 11.5000
STOP WL****.***nm 1700.000 2250.000 600.000
STOP FREQ***.****THz 499.6541 665.0000 176.5000
0nm SWEEP TIME**s MINIMUM 50 MINIMUM
LEVEL
Function Initial Value Maximum Value Minimum Value
REF LEVEL
LOG -10.0 30.0 -90.0
LINEAR 100µW 1000mW 1.00pW
LOG SCALE**.*dB/D 10.0, ON 10.0 0.1
LIN SCALE OFF - -
LIN BASE LEVEL**.*mW 0 REF×0.9 0
AUTO REF LEVEL OFF/ON OFF - -
LEVEL UNIT dBm / dBm/nm / dBm/THz dBm - -
Y SCALE SETTING
Y SCALE DIVISION
8/10/12
10 12 8
REF LEVEL
POSITION **DIV
8 12 0
SUB LOG**.*dB/D 5.0, ON 10 0.1
SUB LIN*.***/D 0.125, OFF 1.250 0.005
SUB SCALE**.*dB/km 5.0, OFF 10.0 0.1
SUB SCALE**.*%/D 10.0 , OFF 125.0 0.5
OFFSET LEVEL**.*dB 0.0 99.9 -99.9
SCALE MIN *.** 0.00 1.25 0.00
OFFSET LEVEL**.*dB/km 0.0 99.9 -99.9
SCALE MIN **.*% 0.0 100.0 0.0
LENGTH**.***km 1.000 99.999 0.001
AUTO SUB SCALE OFF/ON OFF - -
SUB REF LVL POSITION **DIV 5 10 0
9.2 Data Initialization
