9-4
IM AQ6370D-01EN
SETUP
Function Initial Value Maximum Value Minimum Value
RESOLUTION @@@@nm 1 2 0.02
SENS/MODE
NORM/HOLD OFF - -
NORM/AUTO ON - -
NORMAL OFF - -
MID OFF - -
HIGH1 OFF - -
HIGH2 OFF - -
HIGH3 OFF - -
CHOP MODE
OFF/SWITCH
OFF - -
AVG TIMES *** 1 999 1
SAMPLING POINT AUTO ON - -
SAMPLING POINT *****
<SAMPLING POINT AUTO>
calculated value, OFF
50001 101
SAMPLING INTERVAL *.****nm
<SAMPLING POINT AUTO>
calculated value, OFF
SPAN/100 0.001
MEAS WL AIR/VACUUM VAC - -
SWEEP SPEED 1x/2x 1x - -
PLS LIGHT MEASURE OFF - -
TRIGGER SETTING
EDGE RISE/FALL RISE - -
DELAY ****.*ms 0.0 1000.0 0.0
HORZN SCALE nm/THz nm - -
RESOLN CORRECT OFF/ON OFF - -
SMOOTHING OFF/ON OFF - -
FIBER CONNECTOR NORM/ANGLE NORM - -
ZOOM
Function Initial Value Maximum Value Minimum Value
ZOOM CENTER WL ****.***nm
Center wavelength during
measurement of the trace that
was measured or read last
1700.000 600.000
ZOOM CENTER FREQ ***.****THz
Center frequency during
measurement of the trace that
was measured or read last
500.0000 176.5000
ZOOM SPAN WL****.*nm
Measurement span of the
trace that was measured or
read last
1100.0 0.1
ZOOM SPAN FREQ***.****THz
Measurement span of the
trace that was measured or
read last
330.0000 0.0100
ZOOM START WL ****.***nm
Measurement start
wavelength of the trace that
was measured or read last
1699.950 50.000
ZOOM START FREQ ***.****THz
Measurement start frequency
of the trace that was
measured or read last
499.9950 11.5000
ZOOM STOP WL ****.***nm
Measurement stop
wavelength of the trace that
was measured or read last
2250.000 600.050
ZOOM STOP FREQ ***.****THz
Measurement stop frequency
of the trace that was
measured or read last
665.0000 176.5050
OVERVIEW DISPLAY OFF/L/R R - -
OVERVIEW SIZE LARGE/SMALL LARGE - -
9.2 Data Initialization
