DISPLAY
Function Initial Value Maximum Value Minimum Value
NORMAL DISPLAY ON - -
SPLIT DISPLAY OFF - -
SPLIT
DISPLAY
TRACE A UP/LOW UP - -
TRACE B UP/LOW UP - -
TRACE C UP/LOW LOW - -
TRACE D UP/LOW UP - -
TRACE E UP/LOW UP - -
TRACE F UP/LOW LOW - -
TRACE G UP/LOW LOW - -
HOLD
UPPER HOLD
OFF/ON
OFF - -
LOWER HOLD
OFF/ON
OFF - -
LABEL
// AQ6370D OPTICAL
SPCTRUM ANALYZER //
- -
NOISE MASK ***dB OFF 0 OFF(-999)
MASK LINE VERT / HRZN HRZN - -
TRACE
Function Initial Value Maximum Value Minimum Value
ACTIVE TRACE A/B/C/D/E/F/G TRACE A - -
VIEW @ DISP/BLANK
TRACE A=DISP, TRACE B/C/
D/E/F/G =BLANK
- -
FIX @ TRACE B/C/D/E/F/G - -
HOLD @
MAX HOLD
No TRACE ,
TRACE A,C,E,G
- -
MIN HOLD
No TRACE ,
TRACE B,D,F
- -
ROLL AVG * No TRACE , 2 100 2
CALCULATE C
@@@@
LOG MATH @@@@ C=A-B(LOG) , ON - -
LIN MATH @@@@ C=A+B(LIN) , OFF - -
CALCULATE F
LOG MATH @@@@ F=C-D(LOG) , ON - -
LIN MATH @@@@ F=C+D(LIN) , OFF - -
CALCULATE G
LOG MATH @@@@ G=C-F(LOG) , ON - -
LIN MATH @@@@ G=C+F(LIN) , OFF - -
NORMALIZE @@@@ G=NORM A , OFF - -
CURVE FIT
@@@@
G=CRVFIT A , OFF - -
THRESH **dB 20 99 0
OPERATION AREA
ALL / INSIDE L1-L2 /
OUTSIDE L1-L2
ALL - -
FITTING ALGO GAUSS - -
PEAK
CURVE FIT
@@@@
G=PKCVFIT A , OFF - -
THRESH **dB 20 99 0
OPERATION AREA
ALL / INSIDE L1-L2 /
OUTSIDE L1-L2
ALL - -
FITTING ALGO GAUSS - -
TRACE COPY
SOURCE TRACE @ A - -
DESTINATION TRACE @ B - -
9.2 Data Initialization
