3 - 60 CS4070 Scanner Product Reference Guide

Wi-Fi Friendly Channel Exclusion (continued)

Exclude Wi-Fi Channels 1, 6, and 11

(4)

Exclude Wi-Fi Channels 1 and 6

(5)

Exclude Wi-Fi Channels 1 and 11

(6)

Exclude Wi-Fi Channels 6 and 11

(7)
