D - 4 CS4070 Scanner Product Reference Guide

Symbol Code Identifiers

136 UPC-A + 5 supplemental

137 UPC-E0 + 5 supplemental

138 EAN-8 + 5 supplemental

139 EAN-13 + 5 supplemental

144 UPC-E1 + 5 Supplemental

154 Macro MicroPDF

180 GS1 Databar Coupon

183 Han Xin

Table D-1

Bar Code Type Identifiers (Continued)

SDL Code Type ID Bar Code Type

Table D-2

Symbol Code Characters

Code Character Code Type

A UPC-A, UPC-E, UPC-E1, EAN-8, EAN-13

B Code 39, Code 32

C Codabar

Code 128, ISBT 128, ISBT 128 Concatenated

E Code 93

F Interleaved 2 of 5

G Discrete 2 of 5, or Discrete 2 of 5 IATA

H Code 11

JMSI

KGS1-128

L Bookland EAN

M Trioptic Code 39

N Coupon Code

R GS1 DataBar Family

S Matrix 2 of 5

T UCC Composite, TLC 39

U Chinese 2 of 5
