Bluetooth Connection Examples C - 3
Android Pairing Example
1. Press the scan button (+) to wake the scanner.
2. Press and hold the Bluetooth button for five seconds. The scanner beeps and the Bluetooth button blinks
quickly to indicate that the scanner is discoverable by the host.
3. On the Samsung Galaxy Tab 2, tap the Settings icon.
4. Tap Bluetooth. If Bluetooth is not enabled, swipe to enable it. The CS4070 appears in the Available devices
list, indicated by its model name and serial number.
Figure C-3
Samsung Available Devices List
5. Select the CS4070 from the list. A window prompts for a PIN generated by the Samsung Galaxy Tab 2.
Figure C-4
Samsung Pairing Request Window
NOTE To avoid data loss, set KeystrokeDelay on page 1-10 to 70 ms before pairing with the Android.
