Zebra CS4070 User Manual

Symbologies 5 - 15
User-Programmable Supplementals
Supplemental 1: Parameter # 579
SSI # F4h F1h 43h
Supplemental 2: Parameter # 580
SSI # F4h F1h 44h
If you selected a Supplemental User-Programmable option from Decode UPC/EAN/JAN Supplementals on
page 5-12, select User-Programmable Supplemental 1 to set the 3-digit prefix. Then select the 3 digits using
the numeric bar codes beginning on page F-1. Select User-Programmable Supplemental 2 to set a second
3-digit prefix. Then select the 3 digits using the numeric bar codes beginning on page F-1. The default is 000
(zeroes).
UPC/EAN/JAN Supplemental Redundancy
Parameter # 80
SSI # 50h
If you selected Autodiscriminate UPC/EAN/JAN Supplementals, this option adjusts the number of times to
decode a symbol without supplementals before transmission. The range is from two to thirty times. Five or
above is recommended when decoding a mix of UPC/EAN/JAN symbols with and without supplementals. The
default is 10.
Scan the bar code below to set a decode redundancy value. Next, scan two numeric bar codes in Appendix F,
Numeric Bar Codes. Enter a leading zero for single digit numbers. To correct an error or change a selection,
scan Cancel on page F-3.
User-Programmable Supplemental 1
User-Programmable Supplemental 2
UPC/EAN/JAN Supplemental Redundancy
