5 - 84
CS4070 Scanner Product Reference Guide
Maxicode
Parameter # 294
SSI # F0h, 26h
T
o enable or disable Maxicode, scan th
e appropriate bar code belo
w
.
QR Code
Parameter # 293
SSI # F0h, 25h
T
o enable or disable QR Code, scan the appropriate bar
code below
.
Enable Maxicode
(1)
*
Disable Maxicode
(0)
*
Enable QR Code
(1)
Disable QR Code
(0)
201
203
