CS4070 Scanner Product Reference Guide
UPC/EAN
Enable/Disable UPC-A
Parameter # 1
SSI # 01h
T
o enable or disa
ble UPC-A, scan the a
ppropriate bar
code below
.
Enable/Disable UPC-E
Parameter # 2
SSI # 02h
T
o enable or disa
ble UPC-E, scan the a
ppropriate bar
code below
.
*
Enable UPC-A
(1)
Disable UPC-A
(0)
*
Enable UPC-E
(1)
Disable UPC-E
(0)
125
127
