3 - 26 CS4070 Scanner Product Reference Guide
HID Function Key Mapping
Parameter # 1377
SSI # F8h 05h 61h
ASCII values under 32 are normally sent as control-key sequences. When this parameter is enabled, the keys
in bold are sent in place of the standard key mapping (see Table H-1 on page H-1).
Table entries that do not have a bold entry remain the same whether or not this parameter is enabled.
Simulated Caps Lock
Parameter # 1378
SSI # F8h 05h 62h
When enabled, the scanner inverts upper and lower case characters on the scanner bar code as if the Caps
Lock state is enabled on the keyboard. This inversion is done regardless of the current state of the keyboard
Caps Lock state.
*Disable Function Key Mapping
(0)
Enable Function Key Mapping
(1)
*Disable Simulated Caps Lock
(0)
Enable Simulated Caps Lock
(1)
