ASCII Character Sets
H - 11
Table H-6
Extended Keypad Standard Default T
able
Extended Keypad
Keystroke
7001
Break
7002
Delete
7003
Pg Up
7004
End
7005
Pg Dn
7006
Pause
7007
Scroll Lock
7008
Backspac
e
7009
T
ab
7010
Print Screen
701
1
Inse
rt
7012
Home
7013
Enter
7014
Escape
7015
Up Arrow
7016
Dn Arrow
7017
Left Arrow
7018
Right Arrow
312
314
Table of Contents
CS4070 Product Reference Guide
1
Warranty
4
Revision History
5
Table of Contents
7
About This Guide
17
Introduction
17
Configurations
17
Accessories
17
Chapter Descriptions
18
Notational Conventions
19
Related Documents
19
Service Information
20
Getting Started
21
Introduction
21
Unpacking the Scanner
22
Inserting and Removing the Battery
22
Inserting the Battery
22
Removing the Battery
23
Charging Batteries
24
Charging the Battery in a CS4070
24
Charging Spare Batteries
24
Charging Temperature
24
Connecting to the Host Computer
25
Batch Connection
25
Bluetooth Connection: Development Options
25
Pairing
26
Unpairing
27
Deleting the CS4070 from the Device List
27
Configuring the Scanner
28
123Scan2
28
Parameter Bar Codes and Config.ini
28
Updating Scanner Firmware
28
Editing the Configuration File
29
Scanning
33
Introduction
33
Scanning
33
Deleting Bar Codes
34
Transmitting Bar Code Data to Host
34
Transferring Data from a Batch Scanner
34
Transferring Data from a Bluetooth Scanner
35
User Interface Definitions
36
LED Indications
36
Beeper Indications
39
User Preferences
41
Introduction
41
Scanning Sequence Examples
41
Errors While Scanning
41
User Preferences Default Parameters
42
Reset Factory Defaults
45
Set Date and Time
46
Set Date
46
Set Time
46
Cancel Date and Time Setting
46
Bluetooth Options
48
Bluetooth Friendly Name
48
Master/Slave Set Up
49
Bluetooth Unpair
50
Bluetooth Profile
50
Clear Data
51
Auto-reconnect
52
Connection Interval and Discovery Mode Timeout
53
Link Supervision Timeout
54
Bluetooth HID Host Name
55
HID Security
58
Radio Output Power
58
Set HID CoD to Zero
59
Bluetooth HID Keyboard Features
60
Country Keyboard Type
60
HID CAPS Lock Override
63
HID Ignore Unknown Characters
63
Emulate Keypad
64
HID Keyboard FN1 Substitution
65
HID Function Key Mapping
66
Simulated Caps Lock
66
Convert Case
67
Fast Bluetooth HID Keyboard
68
General Decoder Settings
69
Hand-Held Trigger Mode
69
Hand-Held Decode Aiming Pattern
70
Presentation Mode Field of View
71
Decoding Illumination
72
Direct Decode Indicator
73
Low Light Scene Detection
74
Parameter Bar Code Scanning
75
Beep After Good Decode
75
Beeper Volume
76
Beeper Tone
77
Mute Beeper
78
Decode Pager Motor (CS4070HC only)
78
Decode Pager Motor Duration (CS4070HC only)
79
Picklist Mode
80
Fuzzy 1D Processing
81
Mirrored Image
81
Mobile Phone/Display Mode
82
PDF Prioritization
83
PDF Prioritization Timeout
83
Batch Mode
84
Automatic Day/Night Mode
87
Out of Range Electric Fence
91
Continuous Bar Code Read
95
Unique Bar Code Reporting
95
Decode Session Timeout
96
Timeout Between Decodes, Same Symbol
96
Timeout Between Decodes, Different Symbols
97
Wi-Fi Friendly Mode
98
Notes
98
Wi-Fi Friendly Channel Exclusion
99
Data Options
101
Transmit Code ID Character
101
Prefix/Suffix Values
102
Scan Data Transmission Format
103
Transmit “No Read” Message
104
Send Versions
105
Firmware Version
105
Scan Engine Version
105
Dongle Version
105
USB HID Keyboard Features (Dongle)
107
Introduction
107
Scanning Sequence Examples
107
Errors While Scanning
107
USB HID Keyboard Default Parameters
108
USB HID Keyboard Features (Dongle)
109
Country Keyboard Type
109
USB Keystroke Delay
112
USB CAPS Lock Override
113
USB Send Bar Codes with Unknown Characters
113
Emulate Keypad
114
Emulate Keypad with Leading Zero
114
Quick Keypad Emulation
115
USB Keyboard FN 1 Substitution
116
Function Key Mapping
117
Simulated Caps Lock
117
Convert Case
118
Symbologies
119
Introduction
119
Scanning Sequence Examples
119
Errors While Scanning
120
Symbology Default Parameters
120
Enable/Disable All Code Types
125
UPC/EAN
126
Enable/Disable UPC-A
126
Enable/Disable UPC-E
126
Enable/Disable UPC-E1
127
Enable/Disable EAN-8/JAN-8
127
Enable/Disable EAN-13/JAN-13
128
Enable/Disable Bookland EAN
128
Bookland ISBN Format
129
Decode UPC/EAN/JAN Supplementals
130
User-Programmable Supplementals
133
UPC/EAN/JAN Supplemental Redundancy
133
UPC/EAN/JAN Supplemental AIM ID Format
134
Transmit UPC-A Check Digit
135
Transmit UPC-E Check Digit
135
Transmit UPC-E1 Check Digit
136
UPC-A Preamble
137
UPC-E Preamble
138
UPC-E1 Preamble
139
Convert UPC-E to UPC-A
140
Convert UPC-E1 to UPC-A
140
EAN-8/JAN-8 Extend
141
UCC Coupon Extended Code
141
Coupon Report
142
ISSN EAN
142
Code 128
143
Enable/Disable Code 128
143
Set Lengths for Code 128
143
Enable/Disable GS1-128 (formerly UCC/EAN-128)
145
Enable/Disable ISBT 128
145
ISBT Concatenation
146
Check ISBT Table
147
ISBT Concatenation Redundancy
147
Code 128 Security Level
148
Code 39
149
Enable/Disable Code 39
149
Enable/Disable Trioptic Code 39
149
Convert Code 39 to Code 32
150
Code 32 Prefix
151
Set Lengths for Code 39
151
Code 39 Check Digit Verification
153
Transmit Code 39 Check Digit
153
Code 39 Full ASCII Conversion
154
Code 39 Security Level
155
Code 93
156
Enable/Disable Code 93
156
Set Lengths for Code 93
156
Code 11
158
Code 11
158
Set Lengths for Code 11
158
Code 11 Check Digit Verification
160
Transmit Code 11 Check Digits
161
Interleaved 2 of 5 (ITF)
162
Enable/Disable Interleaved 2 of 5
162
Set Lengths for Interleaved 2 of 5
162
I 2 of 5 Check Digit Verification
164
Transmit I 2 of 5 Check Digit
165
Convert I 2 of 5 to EAN-13
165
I 2 of 5 Security Level
166
Discrete 2 of 5 (DTF)
167
Enable/Disable Discrete 2 of 5
167
Set Lengths for Discrete 2 of 5
167
Codabar (NW - 7)
169
Enable/Disable Codabar
169
Set Lengths for Codabar
169
CLSI Editing
171
NOTIS Editing
171
Codabar Upper or Lower Case Start/Stop Characters Detection
172
MSI
173
Enable/Disable MSI
173
Set Lengths for MSI
173
MSI Check Digits
175
Transmit MSI Check Digit(s)
175
MSI Check Digit Algorithm
176
Chinese 2 of 5
177
Enable/Disable Chinese 2 of 5
177
Matrix 2 of 5
178
Enable/Disable Matrix 2 of 5
178
Set Lengths for Matrix 2 of 5
178
Matrix 2 of 5 Check Digit
180
Transmit Matrix 2 of 5 Check Digit
180
Korean 3 of 5
181
Enable/Disable Korean 3 of 5
181
Inverse 1D
182
GS1 DataBar
183
GS1 DataBar-14
183
GS1 DataBar Limited
183
GS1 DataBar Expanded
184
Convert GS1 DataBar to UPC/EAN
184
GS1 DataBar Limited Security Level
185
Composite
186
Composite CC-C
186
Composite CC-A/B
186
Composite TLC-39
187
UPC Composite Mode
188
GS1-128 Emulation Mode for UCC/EAN Composite Codes
189
Postal Codes
190
US Postnet
190
US Planet
190
Transmit US Postal Check Digit
191
UK Postal
191
Transmit UK Postal Check Digit
192
Japan Postal
192
Australia Post
193
Australia Post Format
194
Netherlands KIX Code
195
USPS 4CB/One Code/Intelligent Mail
195
UPU FICS Postal
196
2D Symbologies
197
Enable/Disable PDF417
197
Enable/Disable MicroPDF417
197
Code 128 Emulation
198
Data Matrix
199
GS1 Data Matrix
199
Data Matrix Inverse
200
Decode Mirror Images (Data Matrix Only)
201
Maxicode
202
QR Code
202
QR Inverse
203
MicroQR
204
Aztec
204
Aztec Inverse
205
Han Xin
206
Han Xin Inverse
207
Symbology-Specific Security Levels
208
Redundancy Level
208
Security Level
210
Intercharacter Gap Size
211
Cordless Bluetooth Wedge
213
Introduction
213
123Scan and Software Tools
215
Introduction
215
123Scan
215
123Scan Information
216
Scanner SDK, Other Software Tools, and Videos
217
Scanner Control App
218
Advanced Data Formatting (ADF)
218
Maintenance and Technical Specifications
219
Introduction
219
Maintenance
219
Troubleshooting
220
Technical Specifications
221
Standard Default Parameters
223
Accessories
233
Overview
233
Accessories Summary
234
Single-Slot CS4070 Charging Cradle with Spare Battery Charger
235
Battery Charging Indications
236
Bluetooth Connectivity
236
Eight-Slot CS4070 Charging Cradle
237
Battery Charging Indications
238
Bluetooth Connectivity
238
Eight-Slot Spare Battery Charger
239
Battery Charging Indications
240
LED Indications
240
Wall Mount Brackets
241
KT-102376-01R Bracket
241
KT-102375-01R Bracket
243
Bluetooth to USB HID Dongle
246
Pairing to a USB HID Device
247
Lanyard with Clip
248
Attaching and Removing the Lanyard
248
Bluetooth Connection Examples
249
Overview
249
iPad Pairing Example
250
Android Pairing Example
251
Accessing the Android Phone Keyboard
252
Windows 7 Pairing Example
253
Windows 8 Pairing Example
255
PIN Entry Bar Codes
257
Programming Reference
259
Code Type IDs
259
Symbol Code Identifiers
262
AIM Code Identifiers
264
GS1-128 (formerly UCC/EAN-128)
269
Setting Prefixes and Suffixes
270
Sample Bar Codes
275
UPC-A
275
UPC-E
275
UPC-E1
276
EAN-13
276
EAN-8
276
Code 39
276
Trioptic Code 39
277
Code 93
277
Code 11
277
Codabar
278
MSI
278
Interleaved 2 of 5
278
GS1 DataBar-14
279
PDF417
279
Data Matrix
279
Maxicode
279
QR Code
280
Han Xin
280
US Postnet
280
UK Postal
280
Numeric Bar Codes
281
Numeric Bar Codes
281
Cancel
283
Alphanumeric Bar Codes
285
Alphanumeric Keyboard
285
ASCII Character Sets
303
CJK Decode Control
315
Introduction
315
CJK Decode Control Parameters
316
Unicode Output Control
316
CJK Output Method to Windows Host
317
Unicode/CJK Decode Setup with Windows Host
318
Setting Up the Windows Registry Table for Unicode Universal Output
318
Adding CJK IME on Windows
318
Selecting the Simplified Chinese Input Method on the Host
319
Selecting the Traditional Chinese Input Method on the Host
319
Index
321
Other manuals for Zebra CS4070
Quick Reference Guide
32 pages
4
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Zebra CS4070 and is the answer not in the manual?
Ask a question
Zebra CS4070 Specifications
General
Brand
Zebra
Model
CS4070
Category
Barcode Reader
Language
English
Related product manuals
Zebra CS6080 Series
36 pages
Zebra LS1203
2 pages
Zebra DS2278
22 pages
Zebra LI3608
19 pages
Zebra LI4278
14 pages
Zebra MP7000
210 pages
Zebra DS8178
24 pages
Zebra DS4308
20 pages
Zebra DS6878
14 pages
Zebra RFD8500
118 pages
Zebra DS457 Series
462 pages
Zebra Symbol LI4278
2 pages
To Next PageTo Next PageTo Previous PageTo Previous Page
Loading...
Need help?
General
