Zebra DS2278 Reference Guide

5 - 14 DS2278 Digital Scanner Product Reference Guide
Link Supervision Timeout
Parameter # 1698
SSI # F8h 06h A2h
Link supervision timeout controls how quickly the digital scanner senses that the Bluetooth radio lost connection to
the remote device. A lower value helps prevent data loss at the edge of the operating range while a larger value
helps prevent disconnects due to the remote device not responding in time. If you are experiencing occasional
disconnects and the digital scanner is able to reconnect, increase the link supervision timeout value.
NOTE The digital scanner only controls Link Supervision Timeout in Master Mode.
.5 Seconds
2 Seconds
* 5 Seconds
10 Seconds
20 Seconds

Zebra DS2278 Specifications

General

Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
LED indicators	Yes
Built-in display	No
Housing material	-
International Protection (IP) code	IP42
Type	Handheld bar code reader
Wavelength	645 nm
Sensor type	LED
Scanner type	1D/2D
Tilt reading angle	-65 - 65 °
Motion tolerance (cm/s)	13
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, Interleaved 2 of 5, Plessey, U.P.C.
Optical sensor resolution (W x H)	640 x 480 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, PDF417, QR Code, TLC-39
Battery life	84 h
Input voltage	4.5 - 5.5 V
Battery capacity	2400 mAh
Power source type	Battery, DC
Number of batteries supported	1
USB version	2.0
Bluetooth version	4.0
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Sustainability certificates	RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	90 mm
Width	66 mm
Height	175 mm
Weight	214 g
