Symbologies 12 - 11

EAN-13/JAN-13

Parameter # 3

SSI # 03h

Scan one of the following bar codes to enable or disable EAN-13/JAN-13.

Bookland EAN

Parameter # 83

SSI # 53h

Scan one of the following bar codes to enable or disable Bookland EAN.

*Enable EAN-13/JAN-13

(1)

Disable EAN-13/JAN-13

(0)

Enable Bookland EAN

(1)

*Disable Bookland EAN

(0)

NOTE If you enable Bookland EAN, select a Bookland ISBN Format. Also set Decode UPC/EAN/JAN Supplementals

on page 12-13 to either Decode UPC/EAN/JAN with Supplementals Only, Autodiscriminate UPC/EAN/JAN

With Supplementals, or Enable 978/979 Supplemental Mode.
