Symbologies 12 - 85

Data Matrix

Parameter # 292

SSI # F0h, 24h

Scan one of the following bar codes to enable or disable Data Matrix.

GS1 Data Matrix

Parameter # 1336

SSI # F8h 05h 38h

Scan one of the following bar codes to enable or disable GS1 Data Matrix.

*Enable Data Matrix

(1)

Disable Data Matrix

(0)

Enable GS1 Data Matrix

(1)

*Disable GS1 Data Matrix

(0)
