12 - 10 DS2278 Digital Scanner Product Reference Guide

UPC-E1

Parameter # 12

SSI # 0Ch

Scan one of the following bar codes to enable or disable UPC-E1.

EAN-8/JAN-8

Parameter # 4

SSI # 04h

Scan one of the following bar codes to enable or disable EAN-8/JAN-8.

NOTE UPC-E1 is not a UCC (Uniform Code Council) approved symbology.

Enable UPC-E1

(1)

*Disable UPC-E1

(0)

*Enable EAN-8/JAN-8

(1)

Disable EAN-8/JAN-8

(0)
