12 - 94 DS2278 Digital Scanner Product Reference Guide

Grid Matrix Mirror

Parameter # 1736

SSI # F8h 06h C8h

Scan one of the following bar codes to select a Grid Matrix mirror decoder setting:

• Regular Only - The scanner decodes regular Grid Matrix bar codes only.

• Mirrored Only - The scanner decodes mirrored Grid Matrix bar codes only.

• Auto-discriminate - The scanner decodes both regular and mirrored Grid Matrix bar codes.

*Regular Only

(0)

Mirrored Only

(1)

Autodiscriminate

(2)
