12 - 64 DS2278 Digital Scanner Product Reference Guide

Chinese 2 of 5

Parameter # 408

SSI # F0h 98h

Scan one of the following bar codes to enable or disable Chinese 2 of 5.

Matrix 2 of 5

Parameter # 618

SSI # F1h 6Ah

Scan one of the following bar codes to enable or disable Matrix 2 of 5.

Enable Chinese 2 of 5

(1)

*Disable Chinese 2 of 5

(0)

Enable Matrix 2 of 5

(1)

*Disable Matrix 2 of 5

(0)
