Zebra DS2278

To Next Page

To Previous Page

Symbologies 12 - 79

Composite CC-A/B

Parameter # 342

SSI # F0h 56h

Scan one of the following bar codes to enable or disable Composite bar codes of type CC-A/B.

Composite TLC-39

Parameter # 371

SSI # F0h 73h

Scan one of the following bar codes to enable or disable Composite bar codes of type TLC-39.

Enable CC-A/B

(1)

*Disable CC-A/B

(0)

Enable TLC39

(1)

*Disable TLC39

(0)
