12 - 102 DS2278 Digital Scanner Product Reference Guide

UPU FICS Postal

Parameter # 611

SSI # F1h 63h

Scan one of the following bar codes to enable or disable UPU FICS Postal.

Mailmark

Parameter # 1337

SSI # F8h 05h 39h

Scan one of the following bar codes to enable or disable Mailmark.

Enable UPU FICS Postal

(1)

*Disable UPU FICS Postal

(0)

*Disable Mailmark

(0)

Enable Mailmark

(1)
