APPENDIX F SAMPLE BAR CODES

UPC/EAN

UPC-A, 100%

UPC-A with 2-digit Add-on

IMPORTANT To read a sample barcode the parameter must be enabled. To enable a parameter scan the

appropriate enable barcode in Chapter 12, Symbologies.

0 12345 67890
