xviii DS2278 Digital Scanner Product Reference Guide
Related Product Line Configurations
The product configurations related to the DS2278 digital scanner are as follows.
Cables
The full list of supported cables can be found at:
https://partnerportal.zebra.com/PartnerPortal/product_services/downloads_z/barcode_scanners/Universal-Cable-
Guide-Bar-Code-Scanners.xlsx.
Chapter Descriptions
Topics covered in this guide are as follows:
•
Chapter 1, Getting Started provides a product overview, unpacking instructions, and cable connection
information.
•
Chapter 2, Data Capture provides beeper and LED definitions, techniques involved in scanning bar codes,
general instructions and tips about scanning, and decode ranges.
•
Chapter 3, Maintenance, Troubleshooting, & Technical Specifications provides suggested digital scanner
maintenance, troubleshooting, technical specifications, and signal descriptions (pinouts).
•
Chapter 5, Radio Communications provides information about the modes of operation and features available
for wireless communication. This chapter also includes programming bar codes to configure the digital
scanner.
•
Chapter 4, User Preferences & Miscellaneous Options describes each user preference feature and provides
programming bar codes for selecting these features.
•
Chapter 7, USB Interface describes how to set up the digital scanner with a USB host.
•
Chapter 8, SSI Interface describes the system requirements of the Simple Serial Interface (SSI), which
provides a communications link between Zebra decoders and a serial host.
•
Chapter 9, RS-232 Interface describes how to set up the digital scanner with an RS-232 host.
•
Chapter 10, IBM 468X / 469X Interface describes how to set up the digital scanner with an IBM 468X/469X
host.
•
Chapter 11, Keyboard Wedge Interface describes how to set up a keyboard wedge interface with the digital
scanner.
•
Chapter 12, Symbologies describes all symbology features and provides programming bar codes for
selecting these features for the digital scanner.
NOTES Check Solution Builder for additional information regarding all available accessories, and the latest
available configurations.
Table B:
Accessories for the Digital Scanner
Product ID Description
BTRY-DS22EAB0E-00 Spare Battery, DS2278 Family
BTRY-DS22EAB0E-00K Spare Battery, DS2278 Family, India and South Korea only
25-MCXUSB-01R Micro USB Charge Only Cable
