Zebra DS2278 Reference Guide

5 - 2 DS2278 Digital Scanner Product Reference Guide
Scanning Sequence Examples
In most cases, scanning one bar code sets the parameter value. For example, to enable HID Function Key
Mapping, scan the Enable HID Function Key Mapping bar code listed under HID Function Key Mapping on page
5-20. The digital scanner issues a fast warble beep and the LED turns green, signifying a successful parameter
entry.
Other parameters, such as Bluetooth Friendly Name, require scanning several bar codes. See the parameter
descriptions for this procedure.
Errors While Scanning
Unless otherwise specified, to correct an error during a scanning sequence, just re-scan the correct parameter.
Radio Communications Parameter Defaults
Table 5-1 lists the defaults for radio communication parameters. Change these values in one of two ways:
• Scan the appropriate bar codes in this chapter. The new value replaces the standard default value in
memory. To recall default parameter values, see Default Parameters on page 4-5.
• Configure the digital scanner using the 123Scan configuration program. See Chapter 13, 123Scan and
Software Tools.
NOTE See Appendix A, Standard Default Parameters for all user preference, host, symbology, and
miscellaneous default parameters.
Table 5-1 Radio Communication Default Table
Parameter
Parameter
Number
SSI Number Default
Page
Number
Radio Communications Host Types N/A N/A Cradle Bluetooth
Classic (Cradle Host)
5-4
Bluetooth Friendly Name 607 F1h 5Fh N/A 5-9
Discoverable Mode 610 F1h 62h General 5-10
Wi-Fi Friendly Mode 1299 F8h 05h 77h Disable 5-11
Wi-Fi Friendly Channel Exclusion N/A N/A Use All Channels 5-12
Radio Output Power 1324 F8h 05h 2Ch Medium Power Setting 5-13
Link Supervision Timeout 1698 F8h 06h A2h 5 sec 5-14
Bluetooth Radio State 1354 F8h 05h 4Ah On 5-15
Bluetooth HID - Wait for Connection 1714 F8h 06h B2h Disable 5-15
Apple iOS Virtual Keyboard Toggle 1114 F8h 04h 5Ah Disable 5-16
HID Keyboard Keystroke Delay N/A N/A No Delay (0 msec) 5-17
HID CAPS Lock Override N/A N/A Disable 5-17

Zebra DS2278 Specifications

General

Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
LED indicators	Yes
Built-in display	No
Housing material	-
International Protection (IP) code	IP42
Type	Handheld bar code reader
Wavelength	645 nm
Sensor type	LED
Scanner type	1D/2D
Tilt reading angle	-65 - 65 °
Motion tolerance (cm/s)	13
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, Interleaved 2 of 5, Plessey, U.P.C.
Optical sensor resolution (W x H)	640 x 480 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, PDF417, QR Code, TLC-39
Battery life	84 h
Input voltage	4.5 - 5.5 V
Battery capacity	2400 mAh
Power source type	Battery, DC
Number of batteries supported	1
USB version	2.0
Bluetooth version	4.0
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Sustainability certificates	RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	90 mm
Width	66 mm
Height	175 mm
Weight	214 g
