4 - 8 DS2278 Digital Scanner Product Reference Guide

Beeper Tone

Parameter # 145

SSI # 91h

Scan one of the following bar codes to select a beeper tone for the good decode beep.

Disable Tone

(3)

Low Tone

(2)

*Medium Tone

(1)

High Tone

(0)

Medium to High Tone (2-tone)

(4)
