12 - 96 DS2278 Digital Scanner Product Reference Guide

Postal Codes

US Postnet

Parameter # 89

SSI # 59h

Scan one of the following bar codes to enable or disable US Postnet.

US Planet

Parameter # 90

SSI # 5Ah

Scan one of the following bar codes to enable or disable US Planet.

Enable US Postnet

(1)

*Disable US Postnet

(0)

Enable US Planet

(1)

*Disable US Planet

(0)
