12 - 88 DS2278 Digital Scanner Product Reference Guide

Maxicode

Parameter # 294

SSI # F0h, 26h

Scan one of the following bar codes to enable or disable Maxicode.

QR Code

Parameter # 293

SSI # F0h, 25h

Scan one of the following bar codes to enable or disable QR Code.

Enable Maxicode

(1)

*Disable Maxicode

(0)

*Enable QR Code

(1)

Disable QR Code

(0)
