4 - 14 DS2278 Digital Scanner Product Reference Guide

Timeout to Low Power Mode from Auto Aim

Parameter # 729

SSI # F1 D9

This parameter sets the time the scanner remains in auto aim before entering Low Power Mode.

Disabled

(0)

5 sec

(5)

* 15 sec

(11)

30 sec

(13)

1 minute

(17)
