Zebra DS2278 Reference Guide

Symbologies 12 - 13
Decode UPC/EAN/JAN Supplementals
Parameter # 16
SSI # 10h
Supplementals are bar codes appended according to specific format conventions (e.g., UPC A+2, UPC E+2,
EAN-13+2). The following options are available:
• Decode UPC/EAN/JAN with Supplementals Only - The scanner only decodes UPC/EAN/JAN symbols
with supplemental characters, and ignores symbols without supplementals.
• Ignore UPC/EAN/JAN Supplementals - When presented with a UPC/EAN/JAN plus supplemental
symbol, the scanner decodes UPC/EAN/JAN and ignores the supplemental characters.
• Autodiscriminate UPC/EAN/JAN with Supplementals - The scanner decodes UPC/EAN/JAN symbols
with supplemental characters immediately. If the symbol does not have a supplemental, the scanner must
decode the bar code the number of times set via UPC/EAN/JAN Supplemental Redundancy on page 12-16
before transmitting its data to confirm that there is no supplemental.
Select one of the following Supplemental Mode options to immediately transmit EAN-13 bar codes starting
with that prefix that have supplemental characters. If the symbol does not have a supplemental, the scanner
must decode the bar code the number of times set via UPC/EAN/JAN Supplemental Redundancy on page
12-16 before transmitting the data to confirm that there is no supplemental. The scanner transmits
UPC/EAN/JAN bar codes that do not have that prefix immediately.
• Enable 378/379 Supplemental Mode
• Enable 978/979 Supplemental Mode
• Enable 977 Supplemental Mode
• Enable 414/419/434/439 Supplemental Mode
• Enable 491 Supplemental Mode
• Enable Smart Supplemental Mode - This applies to EAN-13 bar codes starting with any prefix listed
previously.
• Supplemental User-Programmable Type 1 - This applies to EAN-13 bar codes starting with a 3-digit
user-defined prefix. Set this using User-Programmable Supplementals on page 12-16.
• Supplemental User-Programmable Type 1 and 2 - This applies to EAN-13 bar codes starting with either of
two 3-digit user-defined prefixes. Set the prefixes using User-Programmable Supplementals on page 12-16.
• Smart Supplemental Plus User-Programmable 1 - This applies to EAN-13 bar codes starting with any
prefix listed previously or the prefix set using User-Programmable Supplementals on page 12-16.
• Smart Supplemental Plus User-Programmable 1 and 2 - This applies to EAN-13 bar codes starting with
any prefix listed previously or one of the two user-defined prefixes set using User-Programmable
Supplementals on page 12-16.
NOTE If you select 978/979 Supplemental Mode and are scanning Bookland EAN bar codes, see Bookland EAN
on page 12-11 to enable Bookland EAN, and select a format using Bookland ISBN Format on page 12-12.
NOTE To minimize the risk of invalid data transmission, select either to decode or ignore supplemental
characters.

Zebra DS2278 Specifications

General

Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
LED indicators	Yes
Built-in display	No
Housing material	-
International Protection (IP) code	IP42
Type	Handheld bar code reader
Wavelength	645 nm
Sensor type	LED
Scanner type	1D/2D
Tilt reading angle	-65 - 65 °
Motion tolerance (cm/s)	13
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, Interleaved 2 of 5, Plessey, U.P.C.
Optical sensor resolution (W x H)	640 x 480 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, PDF417, QR Code, TLC-39
Battery life	84 h
Input voltage	4.5 - 5.5 V
Battery capacity	2400 mAh
Power source type	Battery, DC
Number of batteries supported	1
USB version	2.0
Bluetooth version	4.0
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Sustainability certificates	RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	90 mm
Width	66 mm
Height	175 mm
Weight	214 g
