Zebra DS2278 Reference Guide

Symbologies 12 - 3
Decode UPC/EAN/JAN Supplementals
(2 and 5 digits)
16 10h Ignore 12-13
User-Programmable Supplementals
Supplemental 1:
Supplemental 2:
579
580
F1h 43h
F1h 44h
000 12-16
UPC/EAN/JAN Supplemental Redundancy 80 50h 10 12-16
Decode UPC/EAN/JAN Supplemental AIM
ID Format
672 F1h A0h Combined 12-17
Transmit UPC-A Check Digit 40 28h Enable 12-18
Transmit UPC-E Check Digit 41 29h Enable 12-18
Transmit UPC-E1 Check Digit 42 2Ah Enable 12-19
UPC-A Preamble 34 22h System Character 12-20
UPC-E Preamble 35 23h System Character 12-21
UPC-E1 Preamble 36 24h System Character 12-22
Convert UPC-E to UPC-A 37 25h Disable 12-23
Convert UPC-E1 to UPC-A 38 26h Disable 12-23
EAN/JAN Zero Extend 39 27h Disable 12-24
UCC Coupon Extended Code 85 55h Disable 12-24
Coupon Report 730 F1h DAh New Coupon
Format
12-25
UPC Reduced Quiet Zone 1289 F8h 05h 09h Disable 12-25
Code 128
Code 128 8 08h Enable 12-26
Set Lengths for Code 128 209, 210 D1h, D2h 1 - 55 12-26
GS1-128 (formerly UCC/EAN-128) 14 0Eh Enable 12-27
ISBT 128 84 54h Disable 12-28
ISBT Concatenation 577 F1h 41h Disable 12-29
Check ISBT Table 578 F1h 42h Enable 12-30
ISBT Concatenation Redundancy 223 DFh 10 12-30
Code 128 <FNC4> 1254 F8h 04h E6h Honor 12-31
Table 12-1 Symbology Parameter Defaults (Continued)
Parameter
Parameter
Number
1
SSI Number
2
Default
Page
Number
1. Parameter number decimal values are used for programming via RSM commands.
2. SSI number hex values are used for programming via SSI commands.

Zebra DS2278 Specifications

General

Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
LED indicators	Yes
Built-in display	No
Housing material	-
International Protection (IP) code	IP42
Type	Handheld bar code reader
Wavelength	645 nm
Sensor type	LED
Scanner type	1D/2D
Tilt reading angle	-65 - 65 °
Motion tolerance (cm/s)	13
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, Interleaved 2 of 5, Plessey, U.P.C.
Optical sensor resolution (W x H)	640 x 480 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, PDF417, QR Code, TLC-39
Battery life	84 h
Input voltage	4.5 - 5.5 V
Battery capacity	2400 mAh
Power source type	Battery, DC
Number of batteries supported	1
USB version	2.0
Bluetooth version	4.0
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Sustainability certificates	RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	90 mm
Width	66 mm
Height	175 mm
Weight	214 g
