A - 8 DS2278 Digital Scanner Product Reference Guide
EAN-8/JAN 8 4 04h Enable 12-10
EAN-13/JAN 13 3 03h Enable 12-11
Bookland EAN 83 53h Disable 12-11
Bookland ISBN Format 576 F1h 40h ISBN-10 12-12
ISSN EAN 617 F1h 69h Disable 12-12
Decode UPC/EAN/JAN
Supplementals
(2 and 5 digits)
16 10h Ignore 12-13
User-Programmable Supplementals
Supplemental 1:
Supplemental 2:
579
580
F1h 43h
F1h 44h
000 12-16
UPC/EAN/JAN Supplemental
Redundancy
80 50h 10 12-16
Decode UPC/EAN/JAN
Supplemental AIM ID Format
672 F1h A0h Combined 12-17
Transmit UPC-A Check Digit 40 28h Enable 12-18
Transmit UPC-E Check Digit 41 29h Enable 12-18
Transmit UPC-E1 Check Digit 42 2Ah Enable 12-19
UPC-A Preamble 34 22h System Character 12-20
UPC-E Preamble 35 23h System Character 12-21
UPC-E1 Preamble 36 24h System Character 12-22
Convert UPC-E to UPC-A 37 25h Disable 12-23
Convert UPC-E1 to UPC-A 38 26h Disable 12-23
EAN/JAN Zero Extend 39 27h Disable 12-24
UCC Coupon Extended Code 85 55h Disable 12-24
Coupon Report 730 F1h DAh New Coupon Format 12-25
UPC Reduced Quiet Zone 1289 F8h 05h 09h Disable 12-25
Code 128
Code 128 8 08h Enable 12-26
Set Lengths for Code 128 209, 210 D1h, D2h 1 - 55 12-26
GS1-128 (formerly UCC/EAN-128) 14 0Eh Enable 12-27
Table A-1 Parameter Defaults (Continued)
Parameter
Parameter
Number
SSI Number Default
Page
Number

Zebra DS2278 Specifications

General

Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
LED indicators	Yes
Built-in display	No
Housing material	-
International Protection (IP) code	IP42
Type	Handheld bar code reader
Wavelength	645 nm
Sensor type	LED
Scanner type	1D/2D
Tilt reading angle	-65 - 65 °
Motion tolerance (cm/s)	13
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, Interleaved 2 of 5, Plessey, U.P.C.
Optical sensor resolution (W x H)	640 x 480 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, PDF417, QR Code, TLC-39
Battery life	84 h
Input voltage	4.5 - 5.5 V
Battery capacity	2400 mAh
Power source type	Battery, DC
Number of batteries supported	1
USB version	2.0
Bluetooth version	4.0
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Sustainability certificates	RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	90 mm
Width	66 mm
Height	175 mm
Weight	214 g
