Zebra DS2278 Reference Guide

Standard Default Parameters A - 11
Matrix 2 of 5
Matrix 2 of 5 618 F1h 6Ah Disable 12-64
Set Lengths for Matrix 2 of 5
Lengths
619
620
F1h 6Bh
F1h 6Ch
4 to 55 12-65
Matrix 2 of 5 Check Digit 622 F1h 6Eh Disable 12-67
Transmit Matrix 2 of 5 Check Digit 623 F1h 6Fh Disable 12-67
Korean 3 of 5
Korean 3 of 5 581 F1h 45h Disable 12-68
Inverse 1D 586 F1h 4Ah Regular 12-69
GS1 DataBar
GS1 DataBar Omnidirectional
(formerly GS1 DataBar-14), GS1
DataBar Truncated, GS1 DataBar
Stacked, GS1 DataBar Stacked
Omnidirectional
338 F0h 52h Enable 12-70
GS1 DataBar Limited 339 F0h 53h Enable 12-70
GS1 DataBar Expanded, GS1
DataBar Expanded Stacked
340 F0h 54h Enable 12-71
Convert GS1 DataBar to
UPC/EAN/JAN
397 F0h 8Dh Disable 12-71
GS1 DataBar Limited Margin Check 728 F1h D8h Level 3 12-72
GS1 DataBar Security Level 1706 F8h 06h AAh Level 1 12-73
Symbology-Specific Security Features
Redundancy Level 78 4Eh 1 12-74
Security Level 77 4Dh 1 12-76
1D Quiet Zone Level 1288 F8h 05h 08h 1 12-77
Intercharacter Gap Size 381 F0h 7Dh Normal 12-78
Composite Codes
Composite CC-C 341 F0h 55h Disable 12-78
Composite CC-A/B 342 F0h 56h Disable 12-79
Composite TLC-39 371 F0h 73h Disable 12-79
Composite Inverse 1113 F8h 04h 59h Regular Only 12-80
Table A-1 Parameter Defaults (Continued)
Parameter
Parameter
Number
SSI Number Default
Page
Number

Zebra DS2278 Specifications

General

Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
LED indicators	Yes
Built-in display	No
Housing material	-
International Protection (IP) code	IP42
Type	Handheld bar code reader
Wavelength	645 nm
Sensor type	LED
Scanner type	1D/2D
Tilt reading angle	-65 - 65 °
Motion tolerance (cm/s)	13
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, Interleaved 2 of 5, Plessey, U.P.C.
Optical sensor resolution (W x H)	640 x 480 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, PDF417, QR Code, TLC-39
Battery life	84 h
Input voltage	4.5 - 5.5 V
Battery capacity	2400 mAh
Power source type	Battery, DC
Number of batteries supported	1
USB version	2.0
Bluetooth version	4.0
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Sustainability certificates	RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	90 mm
Width	66 mm
Height	175 mm
Weight	214 g
