B - 4 DS2278 Digital Scanner Product Reference Guide

Country Codes (Continued)

Bulgarian (Latin)

Bulgarian Cyrillic (Typewriter)

(Bulgarian -Windows XP

Typewriter - Win 7 or higher)

Canadian French Win7

Canadian French (Legacy)

Canadian Multilingual Standard

Chinese (ASCII)
