Zebra DS2278

To Next Page

To Previous Page

CJK Decode Control D - 3

CJK Output Method to Windows Host (continued

Chinese (Simplified) GBK Output

(1)

Chinese (Simplified) Unicode Output

(2)

Korean Unicode Output

(50)

(for Korean Unicode Output, select Simplified Chinese

Unicode IME on the Windows host)

Chinese (Traditional) Big5 Output (Windows XP)

(17)

Chinese (Traditional) Big5 Output (Windows 7)

(19)

Chinese (Traditional) Unicode Output (Windows XP)

(18)

Chinese (Traditional) Unicode Output (Windows 7)

(20)
