Zebra DS2278 Reference Guide

I - 2 DS2278 Digital Scanner Product Reference Guide
1013 $M CTRL M/ENTER
1
CR/ENTER
1014 $N CTRL N SO
1015 $O CTRL O SI
1016 $P CTRL P DLE
1017 $Q CTRL Q DC1/XON
1018 $R CTRL R DC2
1019 $S CTRL S DC3/XOFF
1020 $T CTRL T DC4
1021 $U CTRL U NAK
1022 $V CTRL V SYN
1023 $W CTRL W ETB
1024 $X CTRL X CAN
1025 $Y CTRL Y EM
1026 $Z CTRL Z SUB
1027 %A CTRL [ ESC
1028 %B CTRL \ FS
1029 %C CTRL ] GS
1030 %D CTRL 6 RS
1031 %E CTRL - US
1032 Space Space Space
1033 /A ! !
1034 /B “ "
1035 /C # #
1036 /D $ $
1037 /E % %
1038 /F & &
1039 /G ‘ ‘
Table I-1 ASCII Character Set (Continued)
ASCII Value
(Prefix/Suffix
Value for RS-232)
Full ASCII Code 39
Encode Char
Keystroke
ASCII Character
(Applies to RS-232 Only)
1
The keystroke in bold transmits only if you enabled Function Key Mapping on page 7-15 or page
11-8.
Otherwise, the unbold keystroke transmits.

Zebra DS2278 Specifications

General

Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
LED indicators	Yes
Built-in display	No
Housing material	-
International Protection (IP) code	IP42
Type	Handheld bar code reader
Wavelength	645 nm
Sensor type	LED
Scanner type	1D/2D
Tilt reading angle	-65 - 65 °
Motion tolerance (cm/s)	13
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, Interleaved 2 of 5, Plessey, U.P.C.
Optical sensor resolution (W x H)	640 x 480 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, PDF417, QR Code, TLC-39
Battery life	84 h
Input voltage	4.5 - 5.5 V
Battery capacity	2400 mAh
Power source type	Battery, DC
Number of batteries supported	1
USB version	2.0
Bluetooth version	4.0
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Sustainability certificates	RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	90 mm
Width	66 mm
Height	175 mm
Weight	214 g
