Accessories 2 - 29
Figure 2-32 Disconnect Cup Cables
6. Connect the Battery Adapter power cable to the connector on the cradle.
Figure 2-33 Connect Adapter Power Cable
7. Place adapter onto cradle base and slide toward rear of cradle.
NOTE Place power cable into adapter to avoid pinching cable.
