DICOM Configuration
Parameters:
Definition:
Limit by Modality
 None
 US (ultrasound)
 50+ additional options:
(see list of selections)
Filtering by modality (US, CT, MRI, et cetera) of scheduled patient examination
data generated by the Worklist server. Set according to department requirements.
None: Show entries for all modalities.
US: Show entries for ultrasound exams only.
The following additional modality filter (limit) settings are available for selection:
Selections – AU, BI, CD, CR, CT, DD, DG, DX, ECG, EPS, ES, FID, GM, HC, HD,
IO, IVUA, KO, LS, MG, MR, NM, OP, OT, PR, PT, PX, REG, RF, RG, RTDOSE,
RTIMAGE, RTPLAN, RTRECORD, RWV, SM, SMR, SR, ST, TG, US, XA, XC
Log Level
Defines the level of detail information that will be displayed in the DICOM
Queue.
Maximum entries cached
Enter a number between 0 and 999
Set according to department requirements. A higher number provides access to
more scheduled exams, but increases the time required to search for the exam of
interest.
Minimum/Maximum Film Density
For defining Minimum/Maximum density of images on film. Value entered is
expressed in hundredths of OD (optical density). A value entered of 150,
corresponds with 1.5 OD. Typical acceptable values to be entered are 000-399,
with 020 (for “Min”) and 300 (for “Max”) being a potential starting point.
Network Type
Allows for manual or auto setup of network speed and duplex operational state.
Selections include: Auto-Negotiate, 100MB/Full-Duplex, 100MB/Half-Duplex,
10MB/Full-Duplex, 10MB/Half-Duplex
Nickname
e.g., “Prep Room Printer”
An informal name to identify the device to users in the department. This name is
typically assigned in the department.
Network Usage Type
Defines the interval at which DICOM images will be transferred over the network
to the PACS storage device. Either immediately upon each press of STORE
(“Exam in Progress”), or at the termination of the current examination (“Exam
Completed”).
- Exam In Progress
- Exam Completed
No Color
If selected, images that are captured when the z.one
pro
is being operated in
modalities where no “Color” is present (B-Mode, PW Doppler, M-Mode), will be
transferred to the receiving DICOM device (Network Store system) as
“Grayscale-Monochrome2.
Despite this “No Color” selection being active, all images captured while in Color
Doppler mode will still be transferred to PACS using the color map selected in the
Color Model field.
PDU Receive/Send Size
The size (in bytes) of the basic data packets (PDU: Process Data Unit) that will be
trasferred during receive and transmit operations. (default is 16384 = 16K)
Pixel Spacing
Adds ability to assign CT/MR-specific pixel spacing to ultrasound images sent to
PACS, to allow for calibrating pixels to millimeters for measurements.
Polling Interval (minutes)
 None
 choose minutes
The frequency of automatic updates to the worklist. A short polling interval may
impact system performance. Choose a preferred interval; or choose None to
update the worklist only on demand.
Port number
The TCP/IP port number that is being used by the DICOM device connected to
the system. Default port value is 104.
Queue Timeout (sec)
The maximum amount of time that a DICOM job will remain active in the queue,
before it times out.
Queue Start Type
Defines whether the start of jobs in the DICOM queue will be performed
