Installation and Maintenance Manual - Aastra 5000 AMT/PTD/PBX/0058/4/6/EN
Installation and activation 01/2011 Page 321
• The screen then displays the different configuration modes.
•Select “S" mode then press "Return" to enter the network pre-configuration menu.
The system’s default network pre-configuration is displayed on screen.
It is from this screen, during a first installation, that the defined address can be used to
access the iPBX management function via AMP.
Access is physical via the LAN port on the CPU card front panel.
If it becomes necessary to configure administration and telephony flow seperation, the
address indicated on this screen will be dedicated to the telephony network in association
with the one defined for network administration in the
ADMINISTRATION NETWORK menu.
For this type of configuration, see the specific document :
Operating manual for telephony and administration flow separation
AMT/PTD/PPBX/0101
.
•Press "y" then "Return" to confirm and return to the different fields.
• Enter successively the system parameters, using the Return key to change line.
Configuration mode (F/T/S/P/E)
- F: Factory mode
- T: Total mode
- S: Standard mode
- P: Password reset
- E: for Exit
AASTRA 5000 CONFIGURATION / NETWORK
*-------------------------------------------------*
| ENTER IP ADDRESS: 192.168.65.1
| ENTER NETWORK MASK: 255.255.255.0
| ENTER GATEWAY: 192.168.65.254
*-------------------------------------------------*
DO YOU WANT TO CHANGE CONFIGURATION Y(ES)/N(O) ? Y
