Replacing a non-duplicated RUCV-D CPU card
Table 15:
OPERATION DETAILS OF THE OPERATION / COMMENTS
• Back up the customer
configuration.
• Precautionary operation to be carried out if there is no existing
copy (which is the case when previous installation operations
have been carried out and the procedures followed).
• Refer to [1]
• In the case of remote operation, contact the remote operator
before starting any operation.
• Pull out the faulty card
from its slot.
• Use the 1/4 turn locks to remove the card from its slot
(see Figure 4.1 ).
Nota : The RUCV-D card can be removed from an
operational AXD iPBX.
Nota : When the active RUCV-D card fails, there is loss of
communication with the sets and lines associated
with the cards installed in the expansion cabinet.
• Check that the functional
technical state of the new
card is compatible with
the old one.
.
• Check the configuration of
the card.
• For a card with micro-switches, check that these latter are
configured as they were on the old card, unless the configuration
has been changed (in which case, see Section 4.5).
• As the card may have daughter cards, check that it is fitted in the
same way as the previous one, unless its configuration has been
modified due to a change in its capacity (in which case, see
Section 4.5 and/or the product “Data sheet”).
• Insert the new card into its
slot.
• Slide the card along the card guides until it clicks into place.
• Lock the card in place using the 1/4 turn locks (see Figure 4.1 ).
Nota : The RUCV-D card can be hot-plugged in an
operational AXD iPBX.
• Perform a software check. • Check the software release of the card on the AMP (see
document [1]).
• Contact your distributor if the details do not coincide.
• Check the RUCV-D card
indicators.
For a card fitted with indicators, check that the yellow and/or green
indicators on the front panel are on, and that no red indicator is on
(refer to Section4.5 to check that the operating conditions indicated
by the LEDs are correct).
• Activate the RUCV-D card
from the AMP.
Refer to the document [1].
• Back up the customer
configuration.
