AMT/PTD/PBX/0058/4/6/EN Installation and Maintenance Manual - Aastra 5000
Page 432 01/2011 Maintenance
Replacing a duplicated RUCV-D CPU card
Table 16:
OPERATION DETAILS OF THE OPERATION / COMMENTS
• Back up the customer
configuration.
• Precautionary operation to be carried out if there is no existing
copy (which is the case when previous installation operations
have been carried out and the procedures followed).
• Refer to [1]
• In the case of remote operation, contact the remote operator
before starting any operation.
• Pull out the faulty card
from its slot.
• Use the 1/4 turn locks to remove the card from its slot
(see Figure 4.1 ).
Nota : The RUCV-D card can be removed from an
operational AXD iPBX.
Nota : A failure of the active RUCV-D card triggers a
switchover of the active UCV-D/RUCV-D to the
passive UCV-D/RUCV-D card.
After a switchover the duration of which depends on
the configuration (15 s. to 1 min.), the passive CPU
card takes over and becomes active in the following
three cases:
- if the active card is removed,
- if the active card remains idle for 2 minutes,
- if a hardware failure is detected on the active
RUCV-D card (in this case, a hardware fault
detection is performed. The unavailability time on
the cabinet can, therefore, be up to 3 minutes).
Nota : Of course, this system performs this switchover only
if it does not encounter serious anomalies on the
second UCV-D card.
• Check that the functional
technical state of the new
card is compatible with
the old one.
• Check the configuration of
the card.
• For a card with micro-switches, check that these latter are
configured as they were on the old card, unless the configuration
has been changed (in which case, see Section 4.5).
• As the card may have daughter cards, check that it is fitted in the
same way as the previous one, unless its configuration has been
modified due to a change in its capacity (in which case, see
Section 4.5 and/or the product “Data sheet”).
• Insert the new card into its
slot.
• Slide the card along the card guides until it clicks into place.
• Lock the card in place using the 1/4 turn locks (seeFigure 4.1 ).
Nota : The RUCV-D card can be hot-plugged in an
operational AXD iPBX.
To Next Page
