Installation and Maintenance Manual - Aastra 5000 AMT/PTD/PBX/0058/4/6/EN
Maintenance 01/2011 Page 441
SHEET E-13STANDARD REPLACEMENT OF AN AXS MAIN CABINET
AVAILABILITY
• No mission capable
• 1 operator on site
DURATION
• 30 minutes
• 1 Facom AZXR 10*75 Torx screwdriver for M3 screw (card).
• 1 Facom AZXR 15*75 Torx screwdriver for M4 screw (cover).
INGRÉDIENT(S)/CONSOMMABLE(S)
•N/A
Table 20:
OPERATION DETAILS OF THE OPERATION / COMMENTS
• Back up the customer
configuration.
• Precautionary operation to be carried out if there is no existing
copy (which is the case when previous installation operations
have been carried out and the procedures followed).
• Refer to [1]
• In the case of remote operation, contact the remote operator
before starting any operation.
• Power off the iPBX. • Refer to Section 6.4, Stopping the system (AXD, AXL, AXS,
AXS12 and AXS6)Error! No bookmark name given.
• For a system with several cabinets, first power off the main
cabinet, then the expansion cabinet.
Nota : It is advisable to stop the IPS card before powering off the
iPBX.
• Disconnect the external
cables.
• Disconnect the mains cable.
• Disconnect the cables from the front panel of the UCV card and
those on the cabinet's expansion cards and mark the cables for
refitting.
• For a system with several cabinets, disconnect the cable located
at the rear of the cabinet.
• Remove the cover from
the old cabinet.
• Unscrew the two securing screws of the upper cover, at the back
of the cabinet.
• Remove the upper cover by sliding it backwards.
• Remove the old cabinet.
• Remove the expansion
cards.
• Unlock the cards (see Figure 4.1 ) and pull them out from the
backplane.
